Earthquake seismology great Inge Lehmann

The Mad Scientists of Etsy theme for the month of April is Earthquake Seismology. This was inspired to honour the victims of the Japanese earthquake and tsunami. I decided I did not want to make art about the destructive power of earthquakes. (I'm offering a copy of my moku hanga woodblock print with all proceeds to the Canadian Red Cross for relief of those effected by the disaster. I hope this is more constructive an approach.).

I had been thinking, rather, for some time, of doing a portrait of Inge Lehmann (1888-1993), a Danish (or, as she put it the Danish) seismologist who was at the forefront of the field in the early twentieth century. In 1936, she wrote a paper, entitled simply P', in which she laid out her arguments supporting her discovery of the inner core of the earth.

Inge Lehmann portrait

We now know, as she first postulated, that the earth has roughly three equal concentric sections: mantle, liquid outer core and solid inner core. The crust, on which we live is merely a thin, um, scum really, on top of this slowly boiling pot. The only way to probe deep into the earth's core is to employ massive earthquakes, the waves they generate and the paths they follow. There are two main types of seismic waves used for studies of the globe, unimaginatively named Primary (or P, or compressional) and Secondary (or S, or shear). Imagine a glass of water with a straw; the straw will appear broken at the air-water interface, because light bends as it enters the water. Just like light travelling through different media, these seismic waves can bend, reflect or be transmitted at any boundary. The difference in physical properties between the mantle and outer core causes a P-wave shadow. (For S-waves, the shadow zone is absolute because liquids, like the outer core, do not support shear - imagine trying to cut water with a pair of shears and you can see this for yourself. Thus, no shear waves can make it through the outer core, and thus we can be certain the outer core is fluid). That means, the compressional waves from an earthquake can be recorded at seismic stations out to 105o from an epicentre and then there is a zone which is in the core's shadow. Lehmann found that there were some late-arriving P-waves are much larger angles (142o to 180o) which had been vaguely labelled 'diffractions'. She showed that these could be explained instead by deflections of the waves which travelled through the outer core at her postulated inner core boundary.

She later discovered a discontinuity in the mantle (confusingly also called the Lehmann discontinuity). She did important work well into her 70s and lived to be 105.

When she received the Bowie medal in 1971 (she was the first woman to receive the highest honour of the American Geophysical Union), her citation noted that the "Lehmann discontinuity was discovered through exacting scrutiny of seismic records by a master of a black art for which no amount of computerization is likely to be a complete substitute..." (1, 2).

I think her accomplishment is downright astonishing. To have the exactitude to work with the data and the daring to neglect the irrelevant and offer up a simple, elegant - correct! - explanation is a rare and marvellous thing. To be the top of her field in 1936, when she was a pioneer for women in science and had to compete in vain with incompetent men (her words,1) is heroic.

There are a grand total of two easily found photographs of Lehmann I was able to find on the internet. I based my portrait on the earlier one, to match the date of her phenomenal P' paper. I also show her model of the earth in red-orange ink, complete with mantle, inner and outer core, and travel paths for rays through the layers, including into the shadow zone.
